Super Quality Metallized polypropylene film capacitor cbb21 125j 400v MPP

Features

1. Metallized polypropylene structure
2. Low loss at high frequency
3. Small inherent temperature rise
4. Flame retardant epoxy resin powder coating (UL94 V-0)

Typical Application

1.Widely used in high frequency , DC,AC and pulse circuits
2.Providing optimum performance with small size in S-correction circuits for colour TV set
3.Specially designed for S-correction circuits of large screen monitor and colour TV
4.Suitable for the situation where applies high frequency and high current pulse

Specifications

Reference Standard  GB/T 10190 (IEC 60384-16)

Climatic Category   40/085/21

Rated Temperature   85ºC

Rated Voltage  100V,160V, 200V,250V,400V,630V,1000V,

Capacitance Range  0.001uf~3.3uf

Capacitance Tolerance  ±5%(J) , ±10%(K) , ±20%(M)

Voltage Proof  1.6Ur(5s)

Dissipation Factor  ≤0.1%(20ºC,1KHz)

Insulation Resistance ≥30 000MΩ, Cr≤0.33uf ≥10 000s   Cr>0.33uf     (20ºC,100V,1 min)

Outline Drawing

Dimensions(mm)

Our laboratory



Product Certifications

Every type of our company products has been test by authority, and up to the international standands.
